PHS2C2N002

Li-ion or 4AA / 580lm / 15h

580lm Gen-2 Moonbeam Focus Control Headlight Dual-Fuel with Rec. Battery Pack or 4AA Alkaline Batteries

Available in 1 colour

FOCUS CONTROL
FREE ANGLE ADJUSTMENT

RECHARGEABLE BATTERY OR 4AA ALKALINE

Features -

Specifications +

ANSI +

Hi Power White LED - Up to 580 Lumens
Adjustable Spot to Flood focus beam
Spot Beam for Distance Lighting; Flood Beam for Close Vision
3 Lighting Modes - HIGH, MEDIUM, LOW
2 Lighting Modes (Rear Battery) - ON, 2Hz FLASHING
Red Rear Light for Effective Safety Alert
Direct Plug to Recharge Battery Pack by Micro USB
LED Indicator shows Battery Capacity & Charging Status
Regulated Circuit with Protection from Over-charging & Over-discharging
Runs on either Li-ion Rechargeable Battery Pack [Included] or 4 x AA Alkaline Batteries [Not Included]
1m Drop-proof
IP64 Dust Proof & Water Resistant
** Headstrap design/pattern are for demo only, and will change in mass production

Operation

Headlight
HIGH > MED > LOW > OFF
[Twist the lens ring for LED FOCUS CONTROL]
[Press OFF if stays at any mode over 5 seconds]

Rear Light
ON > 2Hz FLASHING > OFF

Battery Type

1 x 3.7V 6400mAh Li-ion Rechargeable Battery
[Included] or 4 x AA Alkaline Batteries [Not Included]

Charging Info

6hrs Charging Time
Red LED ON - Charging
Green LED ON - Fully Charged

Battery Cycle

300 cycles (Reserves ~70% Capacity after 300 cycles)

Bulb Type

1 x Hi Power White LED

Accessories

Micro USB Cable [Included]

Size

Headlight 67mm x 45mm x 42mm
Battery Case 96mm x 74mm x 47mm

Weight

290g [With Battery]

ANSI
HEADLIGHT HIGH	580 Lumens	10120cd	201m	15h
MED	300 Lumens	5228cd	145m	29h
LOW	60 Lumens	969cd	62m	54h
REAR LIGHT ON	NA	NA	NA	263h
2HZ FLASHING	NA	NA	NA	506h

* Flashing mode specifications cannot be measured by ANSI FL1 standard.
Flashing mode runtime is based on measurement of battery capacity change only.

PHS2C2N002

Li-ion or 4AA / 580lm / 15h
