AH0HC1N003

Li-ion / 2200lm / 10s (boost)


2200lm Hi Power Rechargeable Headlamp


Available in 1 colour
  • BOTH LEDS ON FOR BOOST MODE
  • SINGLE LED FOR SPOT OR FLOOD
  • REAR LIGHT BATTERY CASE
  • Hi-Power White LED – Up to 2200 Lumens
  • Individual SPOT and FLOOD Lens for Long and Close vision
  • Dual Buttons to Switch On separate SPOT and FLOOD LED
  • Safety Red LED Indication on the Rear Battery Case
  • Extremely Hi Power for Industrial Work
  • Direct Plug to Recharge by USB-C
  • Circuit Prot ection Prevents Battery from Over-charging or Over-discharging
  • IP64 Water Resistant and Dust Proof
  • 1M Drop proof
  • Operation
  • Headlight
    Hi Button (SPOT): LOW > MED > HI > OFF
    [Press OFF if stay at any mode for 5 sec]

    Low Button (FLOOD): LOW > MED > HI > OFF
    [Press OFF if stay at any mode for 5 sec]

    When Headlight is in ON mode, long press Hi or Low button for
    2 sec, BOOST mode (2000lm) will be activated. It will be lasted
    For 10 sec, and then return to previous lighting mode

    Rear Light
    ON > 2Hz FLASHING > OFF

    Lock Mode (Headlight)
    [Long press either Hi or Low button for 2 sec to enter lock mode
    (SPOT+FLOOD LED Low blinks twice); Long press for 2 sec to unlock]

    Lock Mode (Battery Case)
    [Long press button of battery case for 2 sec to enter lock mode
    (SPOT+FLOOD LED Low blinks twice); Long press for 2 sec to unlock]

  • Battery Type
  • 2 x 21700 7.2V 4800mAh Li-ion Rechargeable Battery [Included]

  • Charging Info
  • ~5-7hrs Charging Time [DC5V 1000mA Input]
    Red LED ON – Charging
    Green LED ON – Fully Charged

  • Battery Cycle
  • 300 cycles (Reserves ~80% Capacity after 300 cycles)

  • Bulb Type
  • 2 x Hi Power White LED

  • Accessory
  • USB-C Cable [Included]

  • Size
  • Headlight 77mm x 44mm x 42mm
    Battery Case 111mm x 63mm x 44mm

  • Weight
  • 380g [Included Battery]

ANSI
SPOT+FLOOD BOOST 2200 Lumens 6063cd 156m 10s
SPOT HIGH 1000 Lumens 4859cd 139m 9hrs
SPOT MED 530 Lumens 2401cd 98m 14hrs
SPOT LOW 160 Lumens 609cd 49m 35hrs
FLOOD HIGH 1000 Lumens 4071cd 68m 8hrs
FLOOD MED 530 Lumens 549cd 47m 13hrs
FLOOD LOW 150 Lumens 150cd 25m 25hrs
REAR RED ON NA NA NA 353hrs
REAR RED 2Hz FLASHING NA NA NA 628hrs
* Flashing mode specifications cannot be measured by ANSI FL1 standard.
Flashing mode runtime is based on measurement of battery capacity change only.
