PHM0C3A052

3AAA / 240lm / 5h

Compact Light Sensor Headlight,Hands-free Operation & Auto Light Adjustment

Available in 1 colour

Front View
Free Projection Angle

Line up

Seperated Switches
Auto Brightness Adjustment

Features -

Specifications +

ANSI +

Luxeon TX White LED - Up to 240 Lumens
Additional 5mm Nichia Wide Beam LED for Close Vision
Multi-mode Operation: Manual Modes, Light Sensor Mode
Light Sensor Operation adjusts Brightness Instantly and Automatically responding to Environment
Blue Indicator on Switch shows Stand-by Status of Light Sensor Mode
Slim Compact Design, at 96g Weight only
Collimator Lens produces Smooth Long Beam
Operate with 3AAA Batteries
Free Projection Angle
Water Resistant

Colour

White

Operation

Press respective buttons for control under Manual or Sensor Operations.

Manual Modes
LUXEON LED HIGH > LUXEON LED MED > LUXEON LED LOW > 5mm LED ON > LUXEON LED 3Hz FLASHING > OFF
[Press OFF if stays at any mode over 10 seconds]

Light Sensor Mode
LIGHT SENSOR (Blue Indicator ON) > OFF
[Brightness level will be automatically adjusted according to environment. Luxeon LED ON in dark, 5mm LED ON in bright area & close vision]

Battery Type

3 x 1.5V AAA Alkaline Batteries [Included]

Bulb Type

1 x Luxeon TX White LED
1 x Ø5mm Nichia White LED

Size

62mm x 46mm x 40mm

Weight

96g [With Batteries]

ANSI
LUXEON HIGH	240 LUMENS	3250cd	115m	5h
LUXEON MED	105 LUMENS	1400cd	75m	13h
LUXEON LOW	20 Lumens	290cd	35m	60h
5mm ON	15 Lumens	14cd	7m	17h
LUXEON 3Hz FLASHING*	NA	NA	NA	35h

* Flashing mode specifications cannot be measured by ANSI FL1 standard.
Flashing mode runtime is based on measurement of battery capacity change only.

PHM0C3A052

3AAA / 240lm / 5h
